All about electric bike
Electric bike
Basically, electric bicycles can be categorized into two broad categories, depending on the location engine. If
engines are integrated into the wheel hub, often back centrally located
motors are directly integrated into the frame construction in the crank
gear.
engined bike hub motor located in the hub back place, this system is
known as "direct drive" enjoys a propulsion unit stronger and faster,
but does not produce very high torque. And
adding considerable weight and high air resistance, their efficiency is
much reduced compared to the potential that they have. One advantage is that you can recharge partially disengaged when and because they are almost completely silent sliding parts. There and back motor hubs that allow mounting a gear block and appear completely different from normal hubs. Higher
torque offset lower speed, but a big minus is the lack of recharging
option of walking and sliding parts contribute to significantly higher
noise. The engine can be
placed in the front wheel hub, a situation that leads to a feeling of
"all-wheel drive" due to the fact that the rear wheel is driven by the
action of the legs. Feeling concerned may appeal to some, while others are not so excited about it. However,
the main advantage when the engine is part of the front wheel can say
simple repairs and maintenance, because they do not enter into account
complex drivetrain rear wheel. For
motors in the hub back can lead to a higher power, mainly thanks to the
fact that the draft framework can cope better with stress in the back
than in the front, which leads to a lot of other development, adapting
the acceleration, cadence and torque assist. Of
course, remain as important details such as the complicated
installation because drivetrain and shifting the center of gravity back,
using these types of engines centered on the hub back, but generally
are preferred because they feel no different too much from that of
riding a conventional bicycle. Electric
bicycles centrally located engine with the engine centrally located
have a framework designed specifically to accommodate the engine crank
shaft. This design carries
the advantage that does not change anything in the bicycle drivetrain,
allowing the continued use of all gears. Also,
depending on the speed ratio used engine can adapt its contribution,
reaching accurately specified level of assistance increased efficiency,
unlike cylinder engines. More
specifically, if the ascent of a hill, centrally located engine
identifies reduction and increase speed and cadence bike automatically
induced power, which a motor hub is not alone, requiring coordinated by
the person riding. The
center of gravity is nearly unchanged from this type of e-bike closest
thing to conventional bike on the ride, but also in terms of balance and
handling. Perhaps as
important, the engine is located in the center of the frame and battery
attached to one of the pipes triangle previous frame, the electrical
components do not block access to mechanical components, making fixing
the a power, changing the chain, regulatory exchangers or any other
operation specifies a bike as easy to do as with mechanical models. However,
one aspect to remember is that electric motors for bicycles are
intended to assist pedaling, not to take the full load. If the engine works harder than expected, then the user can expect premature component wear. There
would be an alternative in the form of conventional bicycle electric
bicycle which has been fitted conversion, a procedure is very
complicated. Currently on
the market there are a large number of conversion kits that can
materialize this transformation at different levels of power and budget
support. However, using this solution, the result will be very similar to using an electric bike built specifically for this purpose. Conversion kits motor hub are probably the most common such sets. The
series of operations includes replacement wheel forward or back with
one that contains the engine and then connecting electrical circuits in
the control panel and battery, which is located in most cases be the
trunk back or in the media bottle. To
this was added either a pedal sensor that is activated based on the
cadence and the speed with which the pedal is either a system to
maintain a constant predetermined speed and load of the user, regardless
of the speed at which the cadence pedaling. There
are also conversion kits mounted centrally, involving fitting power
unit has provided a framework of building a special place for it. Hence
the event that not all types and models of bikes can also host an
institution and they offer these types of kits is less extensive than in
the previous case. The
wheels of the "all-in-one" come as a very suitable solution for the
conversion of a conventional bicycle into an electric because the rear
wheel houses the motor, battery and control. Such
products have found their consecration in public as a result of
projects materialized through crowdfunding (SuperPedestrian, FlyKly),
mainly due to simplicity - apart from the wheel that houses the
necessary bike have mounted a simple remote control. Appreciation
enjoyed rely on that often have a marginal change bike and control
options via smartphone, as well as other facilities such as self-locking
to prevent theft, only increase the attractiveness enthusiasts gadgets.
If we talk of
disadvantages we must remember that uzitând new technologies and not
widespread, maintenance and repair involves sending the item to the
manufacturer for these operations. Finally, systems of "friction drive" and they made their place on stage bikes that helps to cycling. Motor unit is installed close to the rear wheel and a roller makes contact with it by putting it in motion. The only shortcoming is significantly less power compared to other systems. Vs. pedal assistance Beyond
the constant power all types of electric bicycles, we can mention two
engine modes - those who "assist you" (helps when cycling) pedal and
providing the same amount of power regardless of conditions. ebike-test_veloteca
pedal assistance This mode is often found as the pedelec for the engine
comes into operation only after you start cycling. Triggering
and its operation is subject to keeping moving the pedals, which can be
fun, because you can reach speeds pedaling, but not entirely satisfied
with their power leg. biciclete_electrice_veloteca_test_mtb
Almost all electric bicycles with pedal assistance levels allow
adjusting engine power in accordance with the pedaling, even ten steps
with assistance. The
simplest form of assistance is called cadence sensor system that
provides only the amount of power chosen by the user, regardless of the
difficulty that keeps rhythm selected. More
elaborate systems analyze cadence, torque and speed and they vary
depending on the induced power to keep moving on user defined
parameters. Basically, a variable pitch, the engine generated power decreases or increases depending on the up or down. This
constant power mode (the throttle assist mode) operate as a
conventional engine that generates power once activated indicated by the
user, without taking into account the speed or if the user is riding or
not. Basically, the
mechanism is similar to an accelerator lever mounted on the handlebar or
may have acted as a button with your finger, with which the user
adjusts the engine run. The
advantages are obvious, because the starts of the toughest and most
demanding areas, you can call the engine without being tied pedaling,
but this comes at the cost of higher battery consumption. Also,
in different countries or regions, such electric bicycles are subject
to strict regulation, so you may need special permit or approvals to
use. Finally, more and
more models of e-bikes sites offer both modes either by coupling /
decoupling one or by triggering mode 'throttle' special button once
activated. POWER, AND
BATTERY AUTONOMY Manufacturers will often provide estimates of autonomy
different models of electric bicycles, but these are approximations and
battery level can be influenced by various factors related to use. You
weigh, how much is riding this difference in height of the route, tire
pressure and how loaded is cycling are all factors that will influence
how much does the battery. Even with the same user on the same route, the battery can last more or less depending on wind direction and speed. Ambient
temperature is a key factor in Battery life ... There is no standard
system for determining the exact battery autonomy, similar to the fuel
consumption of cars, but having some basic knowledge of certain
parameters will allow anyone to assess about how it can rely on battery
power. bicicleta_electrica_test POWER engines are classified according to the number of watts. Normally, electric bikes have engines from 250W to 1200W, and with as much power, the greater will be the power consumption. Further,
some relevant characteristics: Voltage / battery voltage is measured in
volts - indicates the potential power of the battery. A higher number of volts provides greater power and typical values are 24V, 36V and 48V. Battery capacity is expressed in Ah (ampere hour) and approximates in Wh. Amp / hour - indicates the number of ampere can be generated in one hour, and usually this value varies between 8 Ah to 20 Ah. Watt / hour - indicates the power stored in the battery calculated in watts / hour. It is obtained by multiplying the voltage of the amp / hour. Typically,
an electric bicycle will consume somewhere between 8:16 watts / hour
per kilometer, the amount varying by factors described in the initial
paragraph of this chapter. So, calculating the number of watts / hour and handing it to estimate watts / km can get a realistic estimate of autonomy. ebike_teste_veloteca
A battery of 400 watts / hour on a flat terrain where it consumes 8
watts / hour per kilometer will have a range of 50 km (400Wh / 8Wh / km =
50 km), after which it will be completely depleted. The
example above is just one example ... and a route rarely be perfectly
flat in zero wind conditions so that the reality facsimile calculation,
so taking a margin of error can be a wise decision. Manufacturers
do not always publish this information fully with presentation
brochures, but being aware of the voltage and the number of amp / hour
remaining value can be deducted. It also recommends some testing on different types of land for a clearer idea of energy. The
most advanced systems provide a real-time estimation of autonomy, even
with the option to display the distance that can still drive by the
battery. With this amount of information available, it becomes increasingly unlikely that the user will run out of power unexpectedly. BATTERY
/ BATTERIES In terms of batteries, most electric bikes use lead-based
batteries or lithium, while nickel is losing ground fast. The most popular at present are those of lithium. Lead - Lead batteries are the most affordable and the most widespread in the world of electric bicycles. Their duration of use is reduced if the discharge is frequently used to the full, and their weight is a disadvantage. Can be almost 6 times heavier than lithium. Nickel-cadmium
- batteries, nickel-cadmium (NiCad) and those of NiMH batteries are
much lighter and have longer battery life as the lead, but just as
polluting the environment as they are, so that environmental regulations
have discouraged powerful their use. NiCd
batteries were banned from trading in the EU, all NiCd NiMH batteries
that cadmium was replaced with a metal hydride and thus was eliminated
the memory effect of NiCd bateriilot. No NiMH batteries are not 'holy' and this is the reason w are undesired. An intermediate are considering a storage capacity / mass unit.
